Product Specifications
Acoustical specifications
Frequency Response: 50 Hz ÷ 20000 Hz
Max SPL @ 1m: 132 dB
Horizontal coverage angle: 100°
Vertical coverage angle: 60°
Transducers
Compression Driver: 1 x 1.4'' neo, 3.0'' v.c
Woofer: 12'', 2.5'' v.c
Input/Output section
Input signal: bal/unbal
Input connectors: XLR, Jack
Output connectors: XLR
Input sensitivity: -2 dBu/+4 dBu
Processor section
Crossover Frequencies: 700Hz
Protections: Thermal, RMS
Limiter: Soft Limiter
Controls: Linear, Boost, Stage, Volume
Power section
Total Power: 2100 W Peak
High frequencies: 700 W Peak
Low frequencies: 1400 W Peak
Cooling: Convection
Connections: VDE
Standard compliance
CE marking: Yes
Physical specifications
Cabinet/Case Material: PP Composite
Hardware: 1 x M10 Top, 1 x M10 each side
Handles: 1 Top , 1 each side
Pole mount/Cap: Yes
Grille: Steel
Color: Black
Size
Height: 642 mm / 25.28 inches
Width: 370 mm / 14.57 inches
Depth: 363 mm / 14.29 inches
Weight: 18.8 kg / 41.45 lbs
Shipping informations
Package Height: 685 mm / 26.97 inches
Package Width: 430 mm / 16.93 inches
Package Depth: 423 mm / 16.65 inches
Package Weight: 21 kg / 46.3 lbs
