Product Specifications

Acoustical specifications

• Frequency Response (-10dB): 60 Hz ÷ 20000 Hz

• Max SPL @ 1m: 128 dB

• Horizontal coverage angle: 100°

• Vertical coverage angle: 60°

• System Sensitivity: 97 dB

Power section

• Amplification: Full Range

• Nominal Impedance: 8 ohm

• Power Handling: 350 W

• Peak Power Handling: 1400 W PEAK

• Recommended Amplifier: 700 W

• Protections: Dynamic Active Mosfet

• Crossover Frequencies: 1400 Hz

Transducers

• Compression Driver: 1.0'', 1.75'' v.c

• Woofer: 10'', 2.5'' v.c

Input/Output section

• Input connectors: Speakon

• Output connectors: Speakon

Standard compliance

• CE marking: Yes

Physical specifications

• Cabinet/Case Material: PP Composite

• Hardware: 1 x M10 top and bottom

• Handles: 1 top

• Pole mount/Cap: Yes

• Grille: Steel

• Colour: Black

Size

• Height: 572.1 mm / 22.52 inches

• Width: 329.9 mm / 12.99 inches

• Depth: 310 mm / 12.2 inches

• Weight: 16.2 kg / 35.71 lbs

Shipping information

• Package Height: 616 mm / 24.25 inches

• Package Width: 370 mm / 14.57 inches

• Package Depth: 390 mm / 15.35 inches

• Package Weight: 18.2 kg / 40.12 lbs
