Product Specifications

Acoustical specifications

• Frequency Response (-10dB): 55 Hz ÷ 20000 Hz

• Max SPL @ 1m: 129 dB

• Horizontal coverage angle: 100°

• Vertical coverage angle: 60°

• System Sensitivity: 97 dB

Power section

• Amplification: Full Range

• Nominal Impedance: 8 ohm

• Power Handling: 400 W

• Peak Power Handling: 1600 W PEAK

• Recommended Amplifier: 800 W

• Protections: Dynamic Active Mosfet

• Crossover Frequencies: 1200 Hz

Transducers

• Compression Driver: 1.0'', 1.75'' v.c

• Woofer: 12'', 2.5'' v.c

Input/Output section

• Input connectors: Speakon

• Output connectors: Speakon

Standard compliance

• CE marking: Yes

Physical specifications

• Cabinet/Case Material: PP Composite

• Hardware: 1 x M10 top, 1 x M10 each side

• Handles: 1 top , 1 each side

• Pole mount/Cap: Yes

• Grille: Steel

• Colour: Black

Size

• Height: 641.6 mm / 25.26 inches

• Width: 369.9 mm / 14.56 inches

• Depth: 363 mm / 14.29 inches

• Weight: 18.2 kg / 40.12 lbs

Shipping information

• Package Height: 685 mm / 26.97 inches

• Package Width: 430 mm / 16.93 inches

• Package Depth: 423 mm / 16.65 inches

• Package Weight: 20.2 kg / 44.53 lbs
