Product Specifications
General
OPTICAL
Light Source: 46 LEDs (10 red, 10 green, 6 blue, 8 amber, 12 lime) 3 to 5 W, (1 A), 50,000 hours life expectancy.
Color Temperature (range): 2800 to 6500 K
CRI (3200 K): 91
Beam Angle: 14° to 43°
Field Angle: 27° to 68°
Zoom Angle: 27° to 68°
Lumens (27°): 1,877 (68°): 2,815
Illuminance (27°): 915 lux @ 5 m (68°): 190 lux @ 5 m
Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz
DYNAMIC EFFECTS
Dimmer: Electronic
Shutter/Strobe: Electronic
Zoom: Motorized
Strobe Rate: 0 to 27 Hz
Standalone Color Mixing: Yes
Color Temperature Presets: Yes
Dim Modes: 4
Built-in Automated Programs: Yes
CONNECTIONS
Power Connection: Edison (Local) plug to Neutrik powerCON
Power Input: Neutrik® powerCON®
Power Output: Neutrik® powerCON®
Data Connectors: 3- and 5-pin XLR
Cable Length (power): 5 ft (1.5 m)
CONTROL
Control Protocol: DMX, RDM
DMX Channels: 3, 5, 7, 11, 13, 14 or 17
Modes/Personalities: 8 personalities (3, 5, 7, 11, 13, 14, 17, HSV)
ELECTRICAL
Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking: 13 units @ 120 V; 22 units @ 208 V; 24 units @ 230 V
Power and Current: 124 W, 1.027 A @ 120 V, 60 Hz
Power and Current: 124 W, 0.608 A @ 208 V, 60 Hz
Power and Current: 126 W, 0.546 A @ 230 V, 50 Hz
CERTIFICATIONS / QUALIFICATIONS
CE, MET
IP Rating: IP20, dry location
Temperature (Ambient): -4 °F to 113 °F (-20 °C to 45 °C)
Physical & Dimensions
Height: 285mm
Width: 241.65mm
Depth: 401.46mm
Weight: 5.6kg
Exterior Color: Black
Housing Material: Aluminum alloy, Aluminum die-cast
Accessory Holder/Gel Frame Size: 6.25 in (158.75 mm)
