Product Specifications

• Acoustical Specifications

  • Frequency Response:  30 Hz ÷ 120 Hz

  • Max SPL @ 1m:  137 dB

• Transducers

  • Woofer:  2 x 18'', 4.0'' v.c

• Input/Output Section

  • Input signal:  bal/unbal

  • Input connectors:  XLR

  • Output connectors:  XLR

  • Input sensitivity:  -2 dBu/+4 dBu

• Processor Section

  • Crossover Frequencies:  Selectable

  • Protections:  Thermal, Excurs., RMS

  • Limiter:  Soft Limiter

  • Controls:  Xover, Phase switch, Deep/Punch, Output Delay Setting

• Power Section

  • Total Power:  4400 W Peak

  • Low frequencies:  4400 W Peak

  • Cooling:  Convection/Forced

  • Connections:  Powercon TRUE1 TOP IN/OUT

• Standard Compliance

  • CE marking:  Yes

• Physical Specifications

  • Cabinet/Case Material:  Plywood

  • Hardware:  2 x M20

  • Handles:  2 x side

  • Grille:  Steel

  • Colour:  Black

• Size

  • Height:  550 mm / 21.65 inches

  • Width:  1180 mm / 46.46 inches

  • Depth:  700 mm / 27.56 inches

  • Weight:  80 kg / 176.37 lbs

• Shipping Information

  • Package Height:  600 mm / 23.62 inches

  • Package Width:  1370 mm / 53.94 inches

  • Package Depth:  900 mm / 35.43 inches

  • Package Weight:  86 kg / 189.6 lbs
