Product Specifications
Acoustical specifications
Frequency Response: 70 Hz ÷ 20000 Hz
Max SPL @ 1m: 127 dB
Horizontal coverage angle: 100°
Vertical coverage angle: 70°
Transducers
Compression Driver: 1 x 1.0'' neo, 1.75'' v.c
Woofer: 2 x 5.0'' neo, 2.0'' v.c
Input/Output section
Input signal: bal/unbal
Input connectors: XLR, RDNet Ethercon
Output connectors: XLR, RDNet Ethercon
Input sensitivity: -2 dBu/+4 dBu
Processor section
Crossover Frequencies: 1200
Protections: Excurs.
Limiter: Fast Limiter
Controls: Bypass, Linear/High Pass, Volume, RDnet on boar
RDNet: Yes
Power section
Total Power: 2000 W Peak, 1000 W RMS
High frequencies: 600 W Peak, 300 W RMS
Low frequencies: 1400 W Peak, 700 W RMS
Cooling: Convection
Connections: Powercon IN/OUT
Standard compliance
CE marking: Yes
Physical specifications
Cabinet/Case Material: Baltic birch plywood
Hardware: 2X M10 TOP AND BOTTOM
2X PIN D.10
Handles: 2 TOP AND BOTTOM
Grille: Steel
Colour: Black
Size
Height: 456 mm / 17.95 inches
Width: 154 mm / 6.06 inches
Depth: 237.5 mm / 9.35 inches
Weight: 9.8 kg / 21.61 lbs
Shipping information
Package Height: 510 mm / 20.08 inches
Package Width: 290 mm / 11.42 inches
Package Depth: 200 mm / 7.87 inches
Package Weight: 11.3 kg / 24.91 lbs
