Product Specifications

• Frequency response (-3 dB) (Hz):  69 Hz – 20,000 Hz

• Frequency range (-10 dB) (Hz):  55 Hz – 20,000 Hz

• Axial sensitivity (dB SPL 1W/1m):  93 dB SPL 1W/1m

• Maximum sound pressure level at a distance of 1 m (dB):  125 dB

• High pass frequency (Hz):  48 Hz

• Crossover frequency (kHz):  2 kHz

• Coverage angle HxV (°):  90° x 60°

• Power handling (continuous) (W):  250 W

• Power handling (peak) (W):  1,000 W

• Nominal impedance (Ω):  8 Ω

• LF transducer:  WECA2128

• LF transducer size (in):  12 in

• LF transducer magnet material:  Ferrite

• HF transducer:  DH-1K

• HF transducer type:  Compression driver

• HF transducer size (in):  1.4 in

• HF transducer diaphragm material:  Titanium

• Dimensions (H x W x D):  621.1 mm x 356.2 mm x 356 mm (24.45 in x 14.02 in x 14.01 in)

• Weight:  14.26 kg (31.44 lb)
